旭日X3支持wiringpi的模块, 但是RDK Ultra没有找到, 下面代码移植就出问题了-
wiringpi.pullUpDnControl(GDO2, wiringpi.GPIO.PUD_UP)
wiringpi.wiringPiISR(GDO2, wiringpi.GPIO.INT_EDGE_FALLING, self.callback)-
RDK Ultra使用Hobot.GPIO中没有相关的设置上拉或下拉电阻的函数?
请问上面代码在RDK Ultra中有没什么办法移植? 谢谢
旭日X3支持wiringpi的模块, 但是RDK Ultra没有找到, 下面代码移植就出问题了-
wiringpi.pullUpDnControl(GDO2, wiringpi.GPIO.PUD_UP)
RDK Ultra使用Hobot.GPIO中没有相关的设置上拉或下拉电阻的函数?
请问上面代码在RDK Ultra中有没什么办法移植? 谢谢
https://developer.d-robotics.cc/rdk\_doc/Basic\_Application/03\_40pin\_user\_guide/gpio
建议尽快寻找替代方案,目前RDK Ultra的系统软件基本不会有更新了。
你好,移植WiringPi需要芯片手册,这块社区没有资源去支持。使用hobot.GPIO的话,能否再提供一下具体是在使用哪一个脚?
也参考了旭日X3派的wiringPI安装, 实际情况为不能使用,有异常
详细出错信息:
root@ubuntu:/# gpio readall
Oops: Unable to determine board revision from /proc/cpuinfo
-> Bogus board_id line (too small)
-> You’d best google the error to find out why.
GPIO.setup(GDO2, GPIO.IN, pull_up_down=GPIO.PUD_UP)
setup有带pull_up_down 参数, 但是这个参数好像没有使用
Hobot.GPIO gpio.py代码
def setup(channels, direction, pull_up_down=None, initial=None):
if not pin_mode:
raise RuntimeError(“No channel mode set”)
if direction not in DIRECTION_LIST:
raise ValueError(“Setup channel direction is invalid”)
if direction == OUT and pull_up_down:
raise RuntimeError("Pull-up and pull-down are not "
“supported in output mode”)
if type(channels) == list or type(channels) == tuple:
pin_names = copy.deepcopy(channels)
elif type(channels) == str or type(channels) == int:
pin_names =
pin_names.append(channels)
else:
raise TypeError(“The channel parameter is of the wrong type”)
for pin_name in pin_names:
if pin_info.__contains__(pin_name):
_cleanup_one(pin_name)
try:
pin_info[pin_name] = PinPro(pin_name)
except Exception as exc:
raise ValueError(“This channel was not found in this mode”)
_export_gpio(pin_name, direction)
if direction == OUT and initial:
output(pin_name, initial)
GDO0, GDO2, CS = 15, 13, 24
GPIO.setmode(GPIO.BOARD) # 物理引脚序号,与开发板的丝印序号一一对应
GPIO.setup(GDO0, GPIO.IN)
GPIO.setup(GDO2, GPIO.IN) # todo pull_up_down参数未实现
#使用的是RDK Ultra 13引脚
